ACCORR 50
ACCORR 50
Enhance your space with our Heavy-Duty ACCORR 50 Doors and Windows, expertly designed for durability, security and elegance. ACCORR 50 is an advanced casement Aluminium Profile system for Inward or Outward, Tophung, Parallel hung , Fix , Tilt & Turn opening windows and Doors. Featuring robust Multipoint with Key cylindrical Mortise locking mechanisms ACCORR 50 prioritize safety and security.
ADVANTAGES
- Choices include single and double shutters.
- Multipoint locking mechanism for windows
- Possibility of double shutter window and Door.
- Proper concealed tower bolt for two-point locking.
- Possibility to fit a mortise lock with a cylinder for Doors.
- Special butt hinges & Door closer for higher load-carrying capacity.
TECHNICAL INFORMATION
| PARTICULAR | SPECIFICATION |
|---|---|
| Small Frame | 50 mm X 46 mm |
| Big Frame | 50 mm X 76 mm |
| Window Shutter Size | 58 mm x 78 mm |
| Door Shutter Size | 58 mm x 92 mm |
| Visible Height of Construction | 106 mm |
| Window Panel Size | 1.22 mtr to 2 mtr |
| Door Panel Size | 1.2 mtr to 3 mtr |
| Glass Glazing Thickness SGU | 6 mm to 12 mm |
| Glass Glazing Thickness DGU | 22 mm to 42 mm |
Experts in Delivering Tailored Engineering Solutions
and Comprehensive After-Sales Support Services.
TYPOLOGY
OTHER CASEMENT series pRODUCTS
