ACCORR 5000
ACCORR 5000
Accorr 5000 Crafted from high-performance profile designs, our this window boast a robust profile that ensures durability and security, making them an ideal choice for both residential and commercial applications. Despite their broader design, our sliding windows are engineered to offer expansive glass panels, flooding your interiors with natural light while maintaining modern look. Accorr 5000 offer smooth functionality, making them a practical addition to any space.
ADVANTAGES
- Special Sash profile with integrated handle.
- Max Glass thickness up to 28mm.
- Range of Typologies available in this system.
- Reduce energy-cost.
- 2/3 Track Frames.
TECHNICAL INFORMATION
| PARTICULAR | SPECIFICATION |
|---|---|
| Frame-2 Track Size | 100 mm x 40 mm |
| Frame-3 Track Size | 150 mm x 40 mm |
| Frame-2 Track Side & Top Size | 100 mm x 50 mm |
| Frame-3 Track Side & Top Size | 150 mm x 50 mm |
| Interlock Size | 50 mm x 47 mm |
| Visible Height of Construction | 87 mm |
| Maximum Panel Size | 2 mtr X 3.35 mtr. |
| Center Meeting Profile Width | 63 mm |
| SS & Aluminium Rail Size | 5 mm X 30 mm |
| Glazing Glass Thickness | 8 mm to 30 mm |
Experts in Delivering Tailored Engineering Solutions and Comprehensive After-Sales Support Services.
